Technical Specifications

Description

GENERAL

Input Channels: 2Output Channels: 4Max Output Power per Channel: 150W (RMS EIAJ Single Channel Driven @ 4 ohm)Minimum Impedance: 4ΩInternal DSP: 28 bit data path with 56 bit inner processingOperating Voltage: 85-264 VACAC Current: 7A NominalWidth: 145mm (5,71in)Height: 90mm (3,54in)Depth: 418mm (16,46in)Rack adapter: G-RACK

AUDIO I/O

Analog balanced I: 2 x Combo jack-XLR female lineAnalog power O: 2 x Speakon (4 pole)

AUDIO CONTROLS

Volume potentiometer | RJ45 connector | DSP can be remotely controlled via an Ethernet connection through Powersoft ArmoniaPlus Software
