Product Features:

• Class D audio amplifier module 4x 2500W @ 4Ω.
• DSP onboard with:- Channel Grouping: group controls over multiple channels;- Input EQ: 3 bands fully parametric equalizer;- Output EQ: 8 bands fully parametric selectable filters: Peaking, High-Shelf, Low-Shelf, High-Pass, Low-Pass, HP-Butterworth, LP-Butterworth;
• Dynamic limiters;
• Signal routing: freely assignable input-to-output signal path with level adjustment;
• Channel delay up to 230 ms.
• Integrated Electronic Brain (IEB) with osKar custom operating system running on quadcore 1.5 GHz internal processor.
• REST API for easy integration with third-party remote control systems.
• K-array Connect mobile app for easy wireless access to the DSP features.
• K-framework3 multiplatform software for loudspeaker system design, managing, tuning and control of multiple units in demanding applications.
