Key Features:

• 4 x 3000 W nominal output power for a total of 12000 W (12K44)4 x 5000 W nominal output power for a total of 20000 W (20K44)4 x 1250 W nominal output power for a total of 5000 W (5K44)Any channel is capable of delivering up to 5900 W power output, from total available power (2000 W for 5K44)
• 2U chassis weighing only 11.4 kg (5K44), 16.5 kg (12K44), 17 kg (20K44)
• Four ‘Lake Class’ analog inputs with Iso-Float™ ground isolation
• Two AES3 on XLR digital inputs (4 audio channels)
• Eight dual-redundant Dante network audio inputs and outputs with AES67 support
• Compatible with PLM, Lake, LM Series and D Series
• Rational Power Management (RPM) - Flexible power output allocation across channels of the 5K44 and 12K44 models to match requirements, enabling more efficient use of amplifier inventory
• Copper-finned Intercooler with transverse-mounted output devices (12K44 and 20K44 only)
• Rugged - road tested construction
• Unique universal, Regulated Switch-Mode Power Supply (R.SMPS™) maintains stability despite mains voltage fluctuations
• Best-in-class Power Factor Correction (PFC) helps maintain full output during extended power bursts
• Current Draw Modelling (CDM™) reduces mains peak draw
• Breaker Emulation Limiter (BEL™) - Tailors PLM+ Series to the available mains distribution
• Under-Voltage Limiting (UVL) enables continued operation with mains voltage sags as low as 65 V
• Power Average Limiter (PAL) with software-controlled Breaker
• Emulation Limiter (BEL) prevents mains fuse tripping
• Amplifier Design: Class TD® output stage (Class D for 5K44)
• Digitally controlled and recallable ‘amplifier gain’ adjustable in 0.1 dB steps
• Digital output attenuation in 0.25 dB steps from -inf to 0 dB
• Digitally implemented, zero-overshoot Inter-Sample Voltage Peak
• Limiting (ISVPL) adjustable in 0.1 V steps from 17.8 to 194 V (150 V for 5K44)
• LoadSmart load verification
• Extensive loudspeaker preset database (LoadLibrary™)
• LoadPilot™, Dual Pilot tone Generating and Monitoring
• CAFÉ Integration
• Dante low-latency digital network included as standard
• Full support for Dante Controller
• Lake’s exclusive classic/linear-phase/FIR speaker processing platform with four throughputs
• Group control with Raised Cosine™ MESA EQ™ asymmetric filters
• LimiterMax™ peak and RMS limiters
• Comprehensive clocking management system with low latency sample rate conversion
• Multiple and redundant inputs with programmable fallover
• Primary and secondary network connections
• High-resolution daylight viewable front-panel LCD display
• Moisture resistant silicone touchpad for front-panel display mode selection and menu navigation
