Technical Specifications

Description

[embed]https://www.youtube.com/watch?v=4FXbpYcQivQ[/embed]

SPECIFICATION

  • Rated Voltage: AC 100 – 240V, 50 / 60Hz
  • Rated Power: 100V 6.0A 550W; 120V 6.5A 750W; 240V 5.5A 1400W
  • Warm-Up Time: 8 minutes (approx.)
  • Fluid Consumption: 9 ml/min (100% Output)
  • Fluid Tank Capacity: 5 Liters (1.32 gallon)
  • Compatible Fluid: - Antari FLG-5E Regular Dense & Regular Dissipating Fog Fluid - Antari FLH-5E Extremely Thin & Fast Dissipating Fog Fluid
  • Operating Time: 9 hrs. (100% output)
  • Ambient Temp. Range: 0°C – 40°C (32°F – 104°F)
  • Control Methods: Manual Timer DMX512 Wireless (Optional) W-DMX (Optional)
  • Interface: - XLR 3-Pin/5-Pin Connector (DMX) - Neutrik powerCON: TRUE 1 (Power)
  • DMX Channels: 2 Channels
  • Included Accessories: N/A
  • Optional Accessories: - WTR-110 Wireless Module - ES-W-DMX Wireless DMX
  • Dimension: L399 W444 H268 mm L15.7 W17.48 H10.56 inch
  • Weight: 6 kg
