GENERAL

• Type: 4ch switching mode, Class D Amplifier
• Output Power: 4x 2000 W @ 4 Ω
• Impedance: minimum 4 Ω
• Frequency Response: 20 Hz – 20 kHz (±1 dB)
• Connections:- 4x XLR (bal) Mic/Line input- 4x XLR (bal) parallel line output- XLR AES3 input & output- KA-POT1 remote volume control inlet- 2x NL4 speakOn loudspeaker output- USB-B / RS485 for remote control
• Built-in DSP: Input gain, routing matrix, delay up to 330 ms, 3x input ch. + 6x output ch. full parametric IIR filters (Peaking, Shelving, Hi/Lo pass, Hi/Lo Butterworth), Onboard preset, Remote monitoring
• Remote control: K-Framework software via USB or RS485
• Protections: Primary AC mains overcurrent/overvoltage, thermal protection, output short circuit, RMS output current protection, high frequency protection, power limiter, clip limiter.
• MAINS Operating Range: 100-240V AC, 50-60 Hz with PFC
• Power Consumption: 600 W @ 4 Ω load, Pink noise, 1/8 rated power
