Box Contents

• 1 x FVE4K-TX
• 1 x FVE4K-RX
• 2 x 12V/2A DC power supply
• 1 x IR emitter
• 1 x IR receiver
• 2 x Mounting kit
• 1 x Quick Reference Guide

Key Features

• Advanced 18Gbps UHD Video over 10Gbps fibre cable with visually lossless compression and zero latency
• Supports HDMI 2.0 18Gbps specification with pass-through for up to 4K 60Hz 4:4:4 and 10/12-bit HDR sources, including Dolby Vision LLM
• Features 1x HDMI loop-out on FVE4K-TX for integrating local displays or cascading to multiple devices
• Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
• USB 1.1 point to point pass-through
• Bi-directional 10/100/1000BaseT Ethernet pass-through
• Supports bi-directional 5V or 12V IR pass-through
• Bi-directional RS-232 pass-through
• HDCP 2.2 compliant with advanced EDID management
• Local 12V 2A power supply required at TX & RX (supplied)

Specifications

FVE4K-RX:

• Video Input Connectors: 1 x SFP+ module video network (SFP+ module not supplied)
• Video Output Connectors: 1 x HDMI Type A, female
• Ethernet Port: 1 x 1Gb LAN RJ45 pass-through
• USB / KVM Port: 2 x USB-Type A (Devices)
• 5V IR Input Port: 1 x 3.5mm stereo jack
• 5V IR Output Port: 1 x 3.5mm mono jack
• RS-232 Port: 1 x 3-pin Phoenix connector
• Power Supply: 12V/2A DC, screw type connector

FVE4K-TX:

• Video Input Connectors: 1 x HDMI Type A, female
• Video Output Connectors: 1 x SFP+ module video network, 1 x HDMI Type A, female (SFP+ module not supplied)
• Ethernet Port: 1 x 1Gb LAN RJ45 pass-through
• USB / KVM Port: 1 x USB-Type B (Host)
• 5V IR Input Port: 1 x 3.5mm stereo jack
• 5V IR Output Port: 1 x 3.5mm mono jack
• RS-232 Port: 1 x 3-pin Phoenix connector
• Power Supply: 12V/2A DC, screw type connector

FVE4K-KIT:

• Casing Dimensions (W x D x H): 180mm x 103mm x 24mm (TX / RX - without connections)
• Casing Dimensions (W x D x H): 180mm x 108mm x 24mm (TX / RX - with connections)
• Shipping Weight: 1.6kg
• Operating Temperature: 32°F to 104°F (0°C to +40°C)
• Storage Temperature: -4°F to 140°F (-20°C to +60°C) Distance capabilities:

The FVE4K-KIT has been designed with 10Gb SFP+ slots to allow for flexible connectivity over varying distances to suit the individual installation, and requirements of different fibre cable types that can be used.

Using SDVoE Technology, the fibre link will need to be 10Gb capable, and Blustream would recommend using SFP+ modules that are designed to work in conjunction with the fibre cable being used. Please use the below as a guide to the distance capabilities of the differing fibre cable types that can be used with the FVE4K-KIT.

• Single mode fibre (OS2) – up to 10km (10Gb Base SE-SR)
• Multimode fibre (OM3) – 300m
• Multimode fibre (OM4) – 400m
• Multimode fibre (OM5) – 300m
