PWR8IEC- 8 Port Managed IEC PDU

Name: PWR8IEC- 8 Port Managed IEC PDU
Brand: Blustream
SKU: PWR8IEC
Price: 2505.81 AED
Availability: InStock

Brand: Blustream

Categories: Power, Smart PDU

SKU: PWR8IEC

The PWR8IEC is an outlet-level metered and switched smart PDU. The unit features 1 x IEC C20 inlet for power, and 8 x IEC C13 output outlets for controlled supply to high-power consumption devices, and a single non-controlled outlet. The PDU supports TCP/IP and RS-232 control, and a redundant TCP/IP port as a back-up. Front panel buttons for manual switching of power to individual outlets, and a single mains switch for overall system power. Relay connections (x8), and 2 x sensor ports can also be used for automatic control of power to both inlet and individual outlet stages when triggered from 3rd party control platforms or BMS systems. Remote access and monitoring can be set-up and achieved via the web-GUI.

Product variants

Low stock, only 1 item left.

Need Help:

Pairs well with

PWR8IEC- 8 Port Managed IEC PDU

Dhs.2,505.81

Technical Specifications

Description

Key Features

Single C20 IEC inlet with 9x C13 IEC outlets (8x controllable outlets + 1x constant outlet)
Products supports 110-250V AC power input up to 16A
Monitoring and metering of Voltage, Current, Power, and Energy Consumption
Overload Protection and Interference Filtering
Advanced power management features including scheduling and power on/off sequencing
Multi-format sensor ports for integration to 3rd party control sensors including temperature, humidity, air pressure, security etc
Control via TCP/IP, RS-232, Front Panel buttons, or Relays
Dual TCP/IP network ports providing uninterrupted network service / access with SSL connectivity
Relays for automated switching of overall or individual power outlets
Provides remote monitoring with password authentication through web-GUI
Support multiple network and IoT protocols
1U design for 19" rack mount integration - Rack mounting kit included

Product Specifications

Power Input ports: 1 x C20 IEC 16A
Power Output ports: 8 x C13 IEC 10A (Controllable) 1 x C13 IEC 10A (Constant)
Relay Control: 4x 3-Pin Phoenix connector
RS-232 serial port: 1 x 3-Pin Phoenix connector
TCP/IP Control: 2 x RJ45, female
Sensor Ports: 2 x RJ45, female
Rack-Mountable: 1U rack height, rack ears included
Dimensions (W x D x H): 437mm x 225mm x 44mm
Dimensions Including Connections (W x D x H): 437mm x 234mm x 44mm
Shipping Weight: 3.0kg TBC
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Power Supply: Internal 110-250V AC

Box Contents

1 x PWR8IEC
1 x Serial cable - DB9 to 3 pin Phoenix connector
4 x 3 pin 3.5mm Phoenix connector
1 x 19" Rack Mounting kit
4 x Mounting feet
1 x Quick Reference Card
IEC Power Cable(s)
