cPot strip - 1 x M8 screw connection, 5x cPot male IN/OUT - CP-BVB5-R

Name: cPot strip - 1 x M8 screw connection, 5x cPot male IN/OUT - CP-BVB5-R
Brand: Contrik
SKU: 1027379
Price: 629.98 AED
Availability: InStock

Dhs.629.98

Brand: Contrik

Categories: Connection Points cPot, Equipotential Bonding System cPot

SKU: 1027379

The cPot Strip is a compact ruggedized distribution box for mobile grounding / potential equalization applications. Rugged EASYLEN® housing is ideally suited for outdoor usage and demanding applications under harsh conditions. 1 x M8 screw connection and 5x cPot male IN/OUT

Product variants

Available

Delivers within 1-2 days

Free delivery above 200 AED

Cash on delivery

14 days returnable

Courier return with a fee

Need Help:

Pairs well with

cPot strip - 1 x M8 screw connection, 5x cPot male IN/OUT - CP-BVB5-R

Dhs.629.98

Technical Specifications

Description

Key Features:

Extreme robust and safe EASYLEN® housing with leather grain texture
Flame retardant (UL94-V2) and non-conductive housing material
High outdoor protection (IP54, IK, ..),
Light weight and compact housing design
Versatile mounting options
Stainless steel screws
M10 thread at the bottom

Technical Specifications:

Electrical

Conductor cross section: Earth bar

Mechanical

Lifetime: > 500 Mating cycles per connector
Locking device: Latch lock
Dimensions: 220 x 77 x 61 mm

Material

Housing: Easylen®
Color: black

Environmental

Standards compatibility: UL94-V2 (connector)
Protection class: IP54 in mated condition
Temperature range: -40 °C to 50°C
