Technical Specifications

Description
  • Split and boost the RDM/DMX signal
  • Power and data optically isolated RDM/DMX ports
  • High voltage protection
  • High brightness Power and Data Status LED indicators
  • DMX line Termination On/Off Switch
  • Velcro straps for ease of installation
  • RDM/DMX Pass-Thru
  • Termination on/off switch
  • Power and Data LED indicators
  • Data inputs: 1 x Neutrik 5 pin XLR
  • Data thru: 1 x Neutrik 5 pin XLR
  • Data outputs: 6 x Neutrik 5 pin XLR
  • Power input: powerCon
  • Input Voltage: AC 88-256V 50/60 Hz
  • Dimensions: 186 x 128 x 124 mm
  • Net Weight: 0.85 Kg
  • Color: Black
