Technical Specifications

Description

SOURCE

  • Light source: 140 x 3 watts Cool White
  • 672 x 0.5 watts RGB LED
  • Color Temperature: 5000-6500K
  • LED life expectancy: 50,000 Hrs.

OPTICAL SYSTEM

  • Beam angle: 120°

DYNAMIC EFFECTS

  • Dimmer: Linear adjustment
  • Color Mixing: RGB
  • Electronic strobe
  • 96 RGB zones control
  • 10 White zones control

CONTROL & PROGRAMMING

  • Control protocols: DMX, Auto, Manual
  • Control channels: 6, 17, 20, 21, 298, 310 CHs
  • LCD Control Panel

ELECTRICAL

  • Input voltage: AC100-240V/50-60Hz
  • Power consumption: 1000 watts

CONNECTIONS

  • DMX connections: 3 pin and 5 pin XLR In/Out male and female
  • Power connections: PowerCon In/Out

PHYSICAL

  • Dimensions: 485 x 250 x 135 mm
  • Net weight: 6.8 Kg
  • Color: Black
  • IP rating: 20
