Technical Specifications

Description

Its compact design, with a total depth of 110 mm (4.3 in) and recessed backcan depth of just 99 mm (3.9 in), allows straightforward installation in ceilings with minimal clearance. Measuring 220 x 220 x 110 mm and weighing 2.7 kg (5.9 lb), it strikes a balance between size, power, and aesthetic discretion. Available in black and white finishes, the DECO series seamlessly matches any interior design.

For optimal performance, pair the DECO-40-T-LP with the INTEGRAL-A402 or INTEGRAL-A404 amplifiers. Using the Integral Matrix and processors, fully compatible with ALMA™, enhances the speakers’ capabilities through custom presets and comprehensive monitoring and control, ensuring effortless system management and maximum audio quality.

The modeling data for DECO-40-T / DECO-40-LP / DECO-65-T / DECO-80-T / DECO-80-TS are valid for EASE Focus, EASE Evac, and EASE Address.

The packaging of this model includes 2 units of the product, 4 ceiling rails, 2 ceiling rings and 2 connector covers.

Performance

  • Frequency Range (-10 dB): 110 Hz – 20 kHz
  • Nominal Impedance: 8 ohms
  • Conical Coverage: 125º
  • Transformer Taps (70 V): 8 Ω / 5 W / 10 W / 15 W
  • Transformer Taps (100 V): 8 Ω / 10 W / 20 W / 30 W
  • RMS Power Handling: 50 W
  • Peak Power Handling: 200 W
  • On-axis Sensitivity (1 W / 1 m): 87 dB SPL
  • Maximum Peak SPL at 1 m: 110 dB

Recommended Electronics

Recommended Amplifiers:

  • INTEGRAL-A402
  • INTEGRAL-A404
  • INTEGRAL-A1002
  • INTEGRAL-A1004
  • INTEGRAL-A1602
  • INTEGRAL-A1604
  • INTEGRAL-MA1004
  • INTEGRAL-MA1604
  • Recommended Processors:
  • INTEGRAL-M88
  • INTEGRAL-MA1604
  • INTEGRAL-MA1004
  • INTEGRAL-M26X

Connectors

  • Audio Input Connector: 4-way Phoenix 3.8 mm
  • Enclosure Geometry: Round
  • Cut-Out Diameter: 185 mm (7.3 in)
  • Dimensions ( H x W x D ): 220 x 220 x 110 mm | 8.7 x 8.7 x 4.3 in
  • Net Weight: 2.3 kg (5.0 lb)

Components

  • MF Driver: 4DCX
