Technical Specifications

Description

SPECIFICATION

Rated Voltage:AC 100-240V 50 / 60 Hz

Rated Power:120V 17A 2,000W ; 240V 8.5A 2,000W

Warm-Up Time:13 Minutes (approx)

Fluid Consumption:400 ml/min (100% Output)

Fluid Tank Capacity:10 Liters (2.64 gallon)

Compatible Fluid:

  • Antari FLG
  • Antari FLY
  • Antari FLJ
  • Antari FLR
  • Antari FLH
  • Antari FLZ

Ambient Temp. Range:0℃ – 40℃ (32℉ – 104℉)

Control:

  • Manual
  • Timer
  • DMX 512
  • Wireless (Optional)
  • Wireless DMX (Optional)

DMX Channels:1 or 3 channels

Connection:

  • Neutrik powerCON TRUE 1 (Power)
  • XLR 3-pin & 5-pin (DMX)

Optional Accessories:

  • WTR-110 Wireless
  • ES-W-DMX Wireless DMX
  • Hanging Bracket

Dimension:

  • L646 W280 H283 mm
  • 43 W11.02 H11.14 inch

Weight:

  • 2 kg
  • 97 lbs
