Specifications

• Maximum fog output: 200 m3 (7,063 ft3) per minute
• Fluid consumption: 2 L (0.53 US gallon) per hour at 2.76 bar/40 psi
• Gas type: CO2 or N2
• Gas consumption: 2.68 kg (5.90 lb) per hour at 2.76 bar / 40 psi
• Control: 4-button LCD user interface, 3 standard DMX512 channels, XLR-5 connectors, RDM compliant.
• Reservoir capacity: 2.5 L (0.66 US gallon)
• APS™ (Automatic Purging System): Standard feature
• Fog colour: Pure white
• Particle size: 0.5 - 0.7 microns
• Warm-up time: 8 minutes (maximum)
• Fluid type: MDG Neutral
• Voltage: 100 - 250 VAC, 50/60 Hz single phase
• Power consumption: 1,415 W
• Enclosure: Weatherproof and dust-resistant
  IP55-rated

Dimensions

• Length: 34 cm (13.4”)
• Width: 48.8 cm (19.2”)
• Height: 60.7 cm (23.9”)
• Weight: 26.3 kg (58 lb)
• Shipping weight: 35.4 kg (78 lb) with flight case
• Approval: CB, CSA and UL Certified. CE Declaration
