Technical Specifications

Description

Specifications

  • Maximum fog output: 800 m3 (28,251 ft3) per minute
  • Fluid consumption: 8 L (2.11 US gallons) per hour at 2.76 bar / 40 psi
  • Gas type: N2
  • Gas consumption: 8 kg (17.6 lb) per hour at 2.76 bar / 40 psi
  • Control: 4-button LCD user interface, 3 standard DMX512 channels, XLR-5 connectors, RDM compliant.
  • Reservoir capacity: 9.5 L (2.51 gallon US)
  • APS™ (Automatic Purging System): Standard
  • Fog colour: Pure white
  • Particle size: 0.5 - 0.7 microns
  • Warm-up time: 8 minutes (maximum)
  • Fluid type: MDG Neutral
  • Operating voltage: 190 - 250 VAC, 50/60 Hz single phase
  • Power consumption: 5 630 W

Dimensions

  • Length: 73 cm (28.7”)
  • Width: 30.4 cm (12”)
  • Height: 41.5 cm (16.3”)
  • Weight: 45 kg (100 lb)
  • Shipping weight: 60 kg (132 lb) with flight case
  • Approval: CB, CSA and UL Certified. CE Declaration
