Specifications

• Maximum fog output per minute: 150 m3 (5,000 ft3)
• Fluid consumption per hour: 3.5 L (O.92 US gallon) at maximum output
• Control: 4-button LCD user interface, 3 standard DMX512 channels, XLR-5 connectors, RDM compliant
• Fluid capacity: 5 L (1.32 US gallon)
• Particle size: 1 - 3 microns
• Warm-up time: 8 minutes (maximum)
• Fluid type: MDG Dense, Low Fog or WB2 Fluid
• Operating voltage (single phase): 190 - 250 VAC, 50/60 Hz monophasé
• Power consumption: 2,815 W

Dimensions

• Length: 49 cm (19”)
• Width: 28 cm (11”)
• Height: 26 cm (10”)
• Weight: 16 kg (35 lb)
• Shipping weight: 27 kg (60 lb) (with flight case)
• Approval: CB, CSA and UL Certified. CE Declaration
