Stainless Steel Design GH12 is made out of Grade 430 stainless steel, an alloy that combines good formability and finish capabilities with an excellent resistance to pitting and corrosion.The high density and neutral sonic characteristics of this material make it a perfectchoiceforapplicationsthat requirecompact design, resistancetoadverse conditions and high sound performance.

Slim Array Technology ® SAT (Slim Array Technology) line arrays show a hyper-cardioid dispersion pattern in the mid-low range frequencies, where conventional line arrays are almost omnidirectional, contributing to a better direction and control. The clarity in the low frequencies and an extremely fast impulse response are the true advantages of slim array speakers. The combination of these two factors leads to a significantly better acoustic outcome with respect to the traditional line array elements, particularly in terms of sound definition and noise pollution outside the desired audience areas.Additionally, the compactness of the speakers benefits the user through the practicality in transporting, the ease of assembly and the overall minimal footprint of the cluster which creates an optimization of space, time and, therefore, total incurred costs for the management of these systems.

GENERAL Continuous power: 200WPeak power: 400WImpedance: 32ΩFrequency range: 125hz – 20khz (-6db average)Maximum SPL(1): 129dB (peak)Continuos SPL: 117dBCoverage: v.30° - H.90°

TRANSDUCERS 12” Coaxial with 1” compression driver ferrite magnet

AUDIO I/O Analog power I: 1 x speakonAnalog power O: 1 x speakon

PHYSICAL OVERVIEWWidth: 327mm (12,87in)Height: 334mm (13,15in)Depth: 198mm (7,79in)Weight: 13,8kg (30,43lbs)Material: stainless steelColor: blackRating: IP54
