This system can be driven by GPZAactive system in a stereo configurationor by GA43 and GA46 power amplifiers.

Thanks to the impressive overall performance and the compact format of the satellites, this system is perfect for high performance outdoor/indoor applications both for rental and permanent installations for touring, large auditoriums, stadia, clubs and pubs, theme parks.User Tip: optimize the cost and combine the system with the active model whether it is for stereo configurations or if need to extend the satellite cluster to form an array.

GENERAL Power Handling: 1500W subwoofer + 400W satellite (200+200W)Peak Power: 3000W subwoofer + 800W satellite (400+400W)Impedance: 4Ω subwoofer + 32Ω each satelliteFrequency Range: 30 Hz - 20 KHz (-6 dB average)Maximum SPL(1): 137dB (peak)Continuos SPL: 125 dBCoverage: V.30° - H.90°

TRANSDUCERS Subwoofer: 2x18” ferrite magnetMid High Frequency: 2x12” coaxial with 1” compression driver ferrite magnet

AUDIO I/O 4 poles speakon connectors

PHYSICAL OVERVIEW

SUBWOOFER Width: 1035mm (40,75in)Height: 614mm (24,17in)Depth: 600mm (23,6in)Weight: 58kg (127,88lbs)Material: birch plywoodRating: IP43

SATELLITE Width: 327mm (12,87in)Height: 334mm (13,15in)Depth: 198mm (7,79in)Weight: 13,8kg (30,43lbs)Material: Stainless SteelRating: IP54
