Technical Specifications

Description

Product features:

  • Inner conductor: Extra Fine wires tinned copper 2x0,34 IEC228 CL5 Ø=1,45 mm
  • Insulation:Foam PE Black/naturalCore arrang.
  • Shield 1:2 twisted conductors with filler
  • Shield 2:Aluminium/my tape, coverage 100%
  • Jacket:Tinned copper braid PVC Ø=6,8 mm
  • Cond.Ohm resistance:<56 Ohm/Km 20N/mm2
  • Shield Ohm resistance:<18 Ohm/Km
  • Insulation resistance:>10000 Mohm*Km
  • Inductance:0,6mH/Km
  • Impedance:120 Ohm
  • Density:1,3 g/cm3
  • Capacitance cond./cond.65pF/m
  • Capacitance cond./shield:102pF/m
  • Test voltage:1000 Volt DC
  • Tensile strenght:20N/mm2
