Photometrics

• LED expected lifetime: 50,000 hours
• Lightsource: 612x CW LED´s (7000K), 680x RGB LED´s
• Type of optical system: native, elliptical lens
• LED PWM Frequency: selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz
• Beam angles @ Full (50%): 66°
• Maximum Field angles @ Full (10%): 108°
• Color temperature range: 2000-10.000K
• CRI/Ra @ Full: 88
• Efficancy @ Full (max): 48.07 lm/W
• Luminous flux @ Full: 57.750 lm (1200W)
• Luminous flux @ Full (illumination mode): 14.807lm (305W)
• Luminous flux @ Center Strobe (Boost Mode): 70.661lm (1135W)
• Luminous flux @ 4x Single Strobes (Boost Mode): 35.582lm (982W)
• Luminous flux @ 2x RGP Panels (Boost Mode): 22.685lm (853W)
• Luminous flux @ Center Strobe (Illumination Mode): 20.260lm (300W)
• Luminous flux @ 4x Single Strobes (Illumination Mode): 14.480lm (300W)
• Luminous flux @ 2x RGP Panels (Illumination Mode): 7.920lm (300W)
• Illuminance Lux @ 3m / 9,84ft (@ Full): 4460lx / 414fcd
• Illuminance Lux @ 3m / 9,84ft (@ Center Strobe): 3500lx / 325fcd
• Illuminance Lux @ 3m / 9,84ft (@ 4x Single Strobes): 2560lx / 238fcd
• Illuminance Lux @ 3m / 9,84ft (@ Center Strobe + 4x Single Strobes): 4045lx / 376fcd
• Illuminance Lux @ 3m / 9,84ft (@ 2x RGB Panels): 1075lx / 100fcd

Thermal Characteristics

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 95%
• Temperature range, Operating: -40°C to 45°C
• Temperature range, Start-Up: -20° to 45°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic over temperature protection

Electrical Data

• AC Power, max: 90 – 285V 50/60Hz
• AC Power, nominal: 100 – 240V 50/60Hz
• Electrical protection: Overload protection with automatic recover
• Max power consumption: 1250W
• Constant power consumption (Illumination Mode): 320W
• Power Max. Out: 6.24A @ 230V / 6.14A @ 120V
• Power Linking @ Max Power Consumption (Boost Mode): 1 unit @ 230V / 0 unit @ 120V
• Power Linking @ Constant Power Consumption (Illumination Mode): 7 units @ 230V / 3 units @ 120V
• Power Factor: 0.998 PF (230V) / 997 PF (120V)
• Power Supply Unit: Inbuilt auto-ranging electronic switch-mode

Operator & Controller

• DMX channels Simple Mode 15CH, Easy Mode 39CH, Standard Mode 71CH (default mode), Pure Mode 112CH Single Pixel 8 Bit with Strobe function, Pure Mode 209CH Single Pixel 16 Bit with Strobe function, Full Access Mode 178CH 8 Bit single Pixel with Pattern, Full Access Extended Mode 275CH 16 Bit with Pattern
• DMX modes: 7
• Protocol: USITT DMX512A RDM ANSI E1.20 Art-Net sACN
• Setting and addressing: OLED graphical display / 4 controls RDM ANSI E1.20
• Standalone mode: Auto Program, Color Macro, Quick Color, Tunable White, User Color
• Wireless DMX: n.a.
• Indicator: OLED graphical display
• Controls: 4 touch sensitive, backlighted controls
• Strobe: 0-30Hz
• DMX I/O: IP65 XLR 5-pin male/female
• Ethernet I/O: IP65 RJ45 Ethernet male/female
• Power In: TRUE1 compatible input & link-thru sockets
• USB Firmware Update: IP65 USB socket

Dimensions & Weight

• IP class: IP65
• IK class: IK08
• Body material: Aluminum, Nylon
• Lens material: Tempered glass front
• Net dimensions without Yoke (w x h x d) : 400 x 200 x 191mm
• Net dimensions inches: 75 x 7.87 x 7.52 inches
• Net weight (incl. Yoke): 6 kgTilt: 360°
• Tilt Locking System: Locking system with toothing and angle indicator

Installation

• Mounting point by Yoke (included): 3x 13mm / 1/2″ holes, 1x centric TV Spigot attachment, 3x integrated Camlocks for Omega Brackets
• Mounting point on fixture: 1/4 turn Omega Bracket on top and rear side
• Mounting point with optional Rigging Bracket: 2x 13mm / 1/2″ holes for Clamp fixation
• Orientation: Any
• Rigging possibilities: Hanging or ceiling / pendant mount
• Safety features: 2x rear mount for safety wire
• Minimum distance from flammable materials: 0.3 meters

Included / Optional

• Included items: Yoke 4.1, 2m Power Cable, Puk
• Accessories: Yoke 2.2, Yoke 4.3, Yoke Floor Extension, Rigging Bracket, Omega Bracket ST, CLUSTER Line Array Fly Bar, CLUSTER Line Array Side Bracket Set, CLUSTER Line Array Backbone 4, CLUSTER Line Array Backbone 2+2, CLUSTER Line Array Floor Bracket
