Technical Specifications

Description

SOURCE

  • Light Source: 150 watts RGBAL LED
  • LED Life Expectancy: 50,000 h

OPTICAL SYSTEM

  • Zoom: Manual zoom
  • Zoom Range: 25° to 80°
  • Accessories: Barn doors included

COLORS

  • Color Mixing: RGBAL

DYNAMIC EFFECTS

  • Strobe effect
  • Macros: Built-in color macros

CONTROL & PROGRAMMING

  • Control Channels: 5/9/11; PAR 150FZ: ARC.1(3CH), AR1.D(4CH), ARC.2(4CH), AR2.D(5CH), AR2.S(6CH), HSV(3CH), STAG(11CH)
  • Control Protocols: DMX, RDM
  • Dimming Curves: 5 Dimming curves
  • LED Frequency: Video flicker free with selectable PWM

THERMAL MANAGEMENT

  • Operating Temperature: -5°C/45°C

CONNECTIONS

  • Power Connections: IP screw type power connection
  • DMX Connections: 3 pin XLR In/Out male and female

ELECTRICAL

  • Input Voltage: AC100-240V/50-60Hz
  • Power Consumption: 150W

PHYSICAL

  • Dimensions: 290 x 260 x 350mm
  • Net Weight: 4 Kg
  • Housing: Aluminum
  • Housing Color: Black
  • IP Rating: IP20
