PR 20 - 20W White Mini Portable LED Profile

Brand: Cyclops Lighting

Categories: LED Fresnels

SKU: PR20W19

PR 20 features compact 30 cm LED profile spot, available in Cool White (PR 20C) and Warm White (PR 20W), powered by a 20-watt COB LED. Both models deliver crisp projections with a high CRI (92) and come with fixed lenses available in 19°, 26°, 36°, or 50°, ensuring an even field of light. For added versatility, optional fresnel lenses are available for a wash effect, while DMX and power track adapters allow for seamless control. These mini LED profiles are ideal for use in museums, art galleries, exhibitions, and retail environments.

Lens: 19°

19°
26°
36°
50°

Color Engine: Warm White

Cool White
Warm White

Product variants

Low stock, only 109 items left.

Need Help:

Pairs well with

PR 20 - 20W White Mini Portable LED Profile

19° / Warm White

Dhs.814.72

Technical Specifications

Description

PR 20W is a super small 30 cm LED profile powered by 20 watts Warm white COB LED. Featuring a fixed Lens of 19°, 26°, 36° or 50°, it delivers a crisp projection and even field with a high CRI of 92. Optional Fresnel lenses are available to get a wash effect from the same LED engine as well as DMX and Power track adapter. This LED Profile can be best deployed in museums, art galleries, exhibitions, and retailer shops.

SOURCE

Light source: 20 watts Warm white LED
Color temperature: 3200 K
LED life expectancy: 50,000 Hrs

OPTICAL SYSTEM

Fixed lens: 19°, 26°, 36° or 50°
Optional Fresnel lenses

PHOTOMETRICS

KEY FEATURES

2 Dimmer curves
Strobe
Video flicker free
Silent operation

CONTROL & PROGRAMMING

Control protocols: Rotary, DMX
Control channels: 1, 3 CHs

ELECTRICAL

Input voltage: AC100-240V/50-60Hz,
Output: 20-42V /600mA DC

CONNECTION

DMX connections: 3 pin XLR In/Out male and female
Power connections: 30-42V/600mA adaptor

PHYSICAL

Dimensions: 295 x 130 x 120mm
Net weight: 1.3 Kg
Color: Black
Housing: Aluminum
IP rating: 20
Operating temperature: -5°C/45°C
