PR 40 - 40W White LED Profile Spot

Brand: Cyclops Lighting

Categories: LED Profiles

SKU: PR40C1530

The PR 40 is a powerful 40-watt LED profile spot, designed to deliver high-performance lighting in a compact, versatile form. The PR 40C features a Cool White LED, while the PR 40W utilizes a Warm White LED, both providing excellent light quality with a CRI of 92. Both models come equipped with a manual zoom function, adjustable from 15° to 30°, allowing for precise control over the beam angle. Their advanced optical systems and high-quality LEDs produce a flat, even field of light, ideal for crisp pattern projection. With DMX control integration, these profile spots are perfect for a range of professional lighting applications.

Color Engine: Cool White

Cool White
Warm White

Housing Color: Black

Black
White

Product variants

Low stock, only 1 item left.

Need Help:

Pairs well with

PR 40 - 40W White LED Profile Spot

Cool White / Black

Dhs.1,239.41

Technical Specifications

Description

SOURCE

Light Source: 40 watts COB LED (Cool White or Warm White)
Illuminance: 3,000 Lux @ 2 m @ 10°
LED Life Expectancy: 50,000 Hr
Color Temperature: 5600 K (Cool White) / 3200 K (Warm White)
CRI (Color Rendering Index): >92
TM-30 Rf (Fidelity Index): >94
TM-30 Rg (Gamut Index): >102
TLCI (Television Lighting Consistency Index): >97

OPTICAL SYSTEM

Zoom Range: 15° to 30° (Manual zoom)

FRAMING SYSTEM

HQ optical system, clean shutter cuts beam

KEY FEATURES

5 Dimmer curves selectable; 16-bit dimming
Color: Cool White / Warm White
RDM data: Available
Video flicker-free
Gobo size: 20 mm

CONTROL & PROGRAMMING

Control Channels: 1, 2, 3, or 4 channels
Control Protocols: Rotary, DMX, RDM
Dimming Curves: 5 selectable dimming curves

THERMAL MANAGEMENT

Operating Temperature: -5°C to 45°C

CONNECTIONS

DMX connections: 3-pin XLR In/Out (male and female)
Power connections: 3-pin power input cable

ELECTRICAL

Input Voltage: AC 100-240 V / 50-60 Hz

PHYSICAL

Dimensions: 402 x 180 x 230 mm
Net Weight: 2.3 kg
Housing: Aluminum
Housing Color: Black
IP Rating: IP20
