Key Features:

• Web interface module for configuration and control of the Blustream Multicast system
• Intuitive 'drag & drop' source selection with video preview feature for active monitoring of system status
• Advanced signal management for independent routing of IR, RS-232, USB / KVM, audio and video
• Auto system configuration
• 2 x RJ45 LAN connections to bridge the existing network to Multicast video distribution network, resulting in:- Better system performance as network traffic is separated- No advanced network setup required- Independent IP address per LAN connection- Allows simplified TCP/IP control of Multicast system
• RS-232 integration for control of Multicast system
• IR integration for control of Multicast system
• PoE (Power over Ethernet) to power Blustream product from a PoE switch
• Local 12V/2A power supply (optional) should Ethernet switch not support PoE (PSU not supplied)
• Support for iOS and Android App control
• 3rd Party drivers available for all major home control brands

Specifications:

• Ethernet port: 2 x LAN RJ45 connector (1 x PoE support)
• RS-232 serial port: 1 x DB-9 female
• RS-232 & I/O port: 1 x 6-Pin Phoenix connector
• IR Input ports: 1 x 3.5mm stereo jack
• Dimensions (W x D x H ): 96mm x 110mm x 26mm
• Shipping Weight: 0.6kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature : -4°F to 140°F (-20°C to 60°C)

Box Contents:

• 1 x ACM200
• 1 x IR Control Cable – 3.5mm to 3.5mm Cable
• 1 x 6-pin Phoenix Connector
• 1 x Mounting Kit
