Photometrics

• LED expected lifetime 50,000 hours
• Lightsource: 2x 300W Red, Green, Royal Blue, Amber, Warm-White
• Type of optical system: Reflector with Compound Eye Lens
• LED PWM Frequency: Selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz
• Beam angles (50%): 50°
• Maximum Field angles (10%): 87°
• Color temperature range: 2000-10.000K
• CRI/Ra: 90 @ 5600K / 86 @ 2900K
• Efficancy (max): 26.15 lm/W
• Luminous flux: 16.215 lm
• Illuminance Lux @ 1m / 3.3ft (@ 2900K): 17.801lx / 1654fcd
• Illuminance Lux @ 3m / 9.8ft (@ 2900K): 1920lx / 178fcd
• Illuminance Lux @ 5m / 16,4ft (@ 2900K): 721lx / 67fcd
• Illuminance Lux @ 7m / 23,0ft (@ 2900K): 398lx / 37fcd
• Illuminance Lux @ 10m / 32,8ft (@ 2900K): 199lx / 18fcd

Thermal Characteristics

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 95%
• Temperature range, Operating: -40°C to 45°C
• Temperature range, Start-up: -20° to 45°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic overtemperature protection

 Electrical Data

• AC Power, max: 90 – 285V 50/60Hz
• AC Power, nominal: 100 – 240V 50/60Hz
• Electrical protection: Overload protection with automatic recover
• Max power consumption (Boost Mode): 620W
• Constant power consumption (Illumination Mode): 220W
• Power Max. Out: 13A @ 230V / 9A @ 120V
• Power Linking @ Max Power Consumption (Boost Mode): 4 units @ 230V / 1 unit @ 120V
• Power Linking @ Constant Power Consumption (Illumination Mode): 15 units @ 230V / 6 units @ 120V
• Power Factor: 0.974 PF (230V) / 0.996 PF (120V)
• Power Supply Unit: Inbuilt auto-ranging electronic switch-mode

Operator & Controller

• DMX Functions: Master Dimmer, Master Dimmer Fine, Shutter, Duration, Dimmer 1-2, Dimmer 1-2 Fine, Red 1-2, Red 1-2 Fine, Green 1-2, Blue 1-2, Blue Fine 1-2, Amber 1-2, Warm-White 1-2, CTC 1-2, Tint 1-2, Color Macro 1-2, Color Macro Crossfade 1-2, Dimmer Curve, Dimmer Response, Redshift, Effect, Device Settings
• DMX channels: 1CH DWE, 2CH DWE, 4CH DWE, 9CH DWE+, 6CH STROBE, 6CH RGB, 10CH BASIC RGB, 14CH BASIC RGB, 11CH SECTION RGB, 11CH Comp RGB, 13CH STANDARD RGB (default), 22CH STANDARD RGB, 24CH EXTENDED RGB, 33CH EXTENDED RGB, 10CH DIRECT, 12CH DIRECT, 17CH DIRECT, 24CH DIRECT, 41CH DIRECT
• DMX modes: 17
• Protocol: USITT DMX512A RDM ANSI E1.20
• Setting and addressing: OLED graphical display / 4 controls RDM ANSI E1.20
• Standalone mode: Auto Program, Color Macro, Quick Color, Tunable White, User Color
• Wireless DMX: n.a.
• Indicator: OLED graphical display
• Controls: 4 touch sensitive, backlighted controls
• Strobe: 0-20Hz
• DMX I/O: IP65 XLR 5-pin male/female
• Power In: TRUE1 compatible input & link-thru sockets
• USB Firmware Update: IP65 USB socket

Dimensions & Weight

• IP class: IP65
• IK class: IK08
• Body material: Aluminum, Nylon
• Lens material: Tempered glass front
• Net dimensions (w x h x d): 400 x 200 x 191mm
• Net dimensions inches: 15.75 x 7.87 x 7.52 inches
• Net weight (incl. Yoke): 10.5 kg
• Tilt: 360°
• Tilt Locking System: Locking system with toothing and angle indicator

Installation

• Mounting point by Yoke (included): 3x 13mm / 1/2″ holes, 1x centric TV Spigot attachment, 3x integrated Camlocks for Omega Brackets
• Mounting point on fixture: 1/4 turn Omega Bracket on top and rear side
• Mounting point with optional Rigging Bracket: 2x 13mm / 1/2″ holes for Clamp fixation
• Orientation: Any
• Rigging possibilities: Hanging or ceiling / pendant mount
• Safety features: 2x rear mount for safety wire
• Minimum distance from flammable materials: 0.3 meters
