Photometrics

• LED expected lifetime 50,000 hours
• Lightsource 4x 300W Warm-White + Amber + Red
• Type of optical system Reflector with Compound Eye Lens
• LED PWM Frequency selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz
• Beam angles (50%) 50°
• Maximum Field angles (10%) 87°
• Color temperature range 2.900K
• CRI/Ra 80
• Efficancy (max) 25,19 lm/W
• Luminous flux 34.000 lm
• Illuminance Lux @ 1m / 3,3ft 37870lx / 3518fcd
• Illuminance Lux @ 3m / 9,8ft 4295lx / 399fcd
• Illuminance Lux @ 5m / 16,4ft 1535lx / 143fcd
• Illuminance Lux @ 7m / 23,0ft 795lx / 74fcd
• Illuminance Lux @ 10m / 32,8ft 395lx / 37fcd

 Thermal Characteristics

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 95%
• Temperature range, Operating: -40°C to 45°C
• Temperature range, Start-up: -20°C to 45°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic overtemperature protection

Electrical Data

• AC Power, max: 90 – 285V 50/60Hz
• AC Power, nominal: 100 – 240V 50/60Hz
• Electrical protection: Overload protection with automatic recover
• Max power consumption (Boost Mode): 1350W
• Constant power consumption (Illumination Mode): 440W
• Power Max.: Out 9A @ 230V / 2A @ 120V
• Power Linking @ Max Power Consumption (Boost Mode): 1 unit @ 230V / 0 unit @ 120V
• Power Linking @ Constant Power Consumption (Illumination Mode): 7 units @ 230V / 2 units @ 120V
• Power Factor: 0.944 PF (230V) / 998 PF (120V)
• Power Supply Unit: Inbuilt auto-ranging electronic switch-mode

 Operator & Controller

• DMX Functions Master Dimmer, Master Dimmer Fine, Shutter, Duration, Dimmer 1-4, Dimmer 1-4 Fine, Dimmer Curve, Dimmer Response, Redshift, Effect, Device Settings
• DMX channels 1CH DWE, 4-1CH DWE, 4-2CH DWE, 7CH STROBE, 9CH STANDARD (default), 12CH EXTEN
• DED, 17CH EXTENDED
• DMX modes: 7
• Protocol USITT DMX512A RDM ANSI E1.20
• Setting and addressing: OLED graphical display / 4 controls RDM ANSI E1.20
• Standalone mode: Auto Program, Quick Light
• Wireless DMX: n.a.
• Indicator: OLED graphical display
• Controls: 4 touch sensitive, backlighted controls
• Strobe: 0-20Hz
• DMX I/O: IP65 XLR 5-pin male/female
• Power In: TRUE1 compatible input & link-thru sockets
• USB Firmware Update: IP65 USB socket

Dimensions & Weight

• IP class: IP65
• IK class: IK08
• Body material: Aluminum, Nylon
• Lens material: Tempered glass front
• Net dimensions (w x h x d): 400 x 400 x 191mm
• Net dimensions inches: 15.75 x 15.75 x 7.52 inches
• Net weight (incl. Yoke) 16.2 kg
• Tilt: 360°
• Tilt Locking System: Locking system with toothing and angle indicator

Installation

• Mounting point by Yoke (included) 3x 13mm / 1/2" holes, 1x centric TV Spigot attachment, 3x integrated Camlocks for Omega Brackets
• Mounting point on fixture 1/4 turn Omega Bracket on top and rear side
• Mounting point with optional Rigging Bracket 2x 13mm / 1/2" holes for Clamp fixation
• Orientation: Any
• Rigging possibilities: Hanging or ceiling / pendant mount
• Safety features: 2x rear mount for safety wire
• Minimum distance from flammable materials: 0,3 meters

Included / Optional

• Included items Yoke 4.2, 2m Power Cable, Puk
• Optional Accessories: Yoke 4.3, Yoke Floor Extension, Rigging Bracket G2, Omega Bracket ST, Floor Bracket, CLUSTER Line Array Fly Bar, CLUSTER Line Array Side Bracket Set, CLUSTER Line Array Backbone 4, CLUSTER Line Array Backbone 2+2, CLUSTER Line Array Floor Bracket
