Photometrics

• LED expected lifetime: 50.000 hours
• Light source: 288 x CW LED´s (7000K), 720 x RGB LED´s
• Type of optical system: native, elliptical lens
• LED PWM Frequency: selectable 800Hz, 1.200Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz
• Beam angles @ Full (50%): 66°
• Maximum Field angles @ Full (10%): tba
• Color temperature range: tba
• CRI/Ra @ Full: tba
• Efficancy @ Full (max): tba
• Luminous flux @ Full: tba
• Luminous flux @ 2x Single Strobes (Boost Mode): tba
• Luminous flux @ 2x Single Strobes (Illumination Mode): tba
• Luminous flux @ 2x RGB Panel (Illumination Mode): tba
• Illuminance Lux @ 3m / 9,84ft (@ Full / Boost Mode): tba
• Illuminance Lux @ 3m / 9,84ft (@ 2x Single Strobes / Boost Mode): tba
• Illuminance Lux @ 3m / 9,84ft (@ RGB Panel): tba

Thermal Characteristics

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 95%
• Temperature range, operating: -40°C to 45°C
• Temperature range, Start-Up: -20° to 45°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic over temperature protection

Electrical Data

• AC Power, max: 90 – 285V 50/60Hz
• AC Power, nominal: 100 – 240V 50/60Hz
• Electrical protection: Overload protection with automatic recover
• Max power consumption: 1010W
• Constant power consumption (Illumination Mode): 215W
• Power Max. Out @ Max.Power Consumption: 3.97A @ 230V (910W) / 11,3A @ 100V (970W)
• Power Max. Out @ Constant Power Consumption: 0.99A @ 230V (215W) / 2,24A @ 100V (220W)
• Power Linking @ Max Power Consumption (Boost Mode): 3 units @ 230V / 0 unit @ 100V
• Power Linking @ Constant Power Consumption (Illumination Mode): 11 units @ 230V / 4 units @ 100V
• Power Factor @ Max. Power Consumption (Boost Mode): 0.88PF @ 100V / 1.00PF @ 230V
• Power Factor @ Constant Power Consumption (Illumination Mode): 0.985PF @ 100V / 0.981 PF @ 230V
• Power Supply Unit: Inbuilt auto-ranging electronic switch-mode

Operator & Controller

• DMX channels 12CH Simple, 27CH Easy, 44CH Standard, 138CH Pure, 269CH Pure Extended Mode, 166CH Full Access, 297CH Full Access Extended, 100CH Pure S2 Merge Mode
• DMX modes: 8
• Protocol: USITT DMX512A RDM ANSI E1.20 Art-Net sACN
• Setting and addressing: OLED graphical display / 4 controls RDM ANSI E1.20
• Standalone mode: Auto Program, Color Macro, Quick Color, Tunable White, User Color
• Wireless DMX: n.a.
• Indicator: OLED graphical display
• Controls: 4 touch sensitive, backlighted controls
• Strobe: 0-30Hz
• DMX I/O: IP65 XLR 5-pin male/female
• Ethernet I/O: IP65 RJ45 Ethernet male/female
• Power In: TRUE1 compatible input & link-thru sockets
• USB Firmware Update: IP65 USB socket

Dimensions & Weight

• IP class: IP65
• IK class: IK06
• Body material: Aluminum, Nylon
• Lens material: Tempered glass front
• Net dimensions without Yoke (w x h x d): 800 x 100 x 182,5mm
• Net dimensions inches: 31.49 x 3.93 x 7.19 inches
• Net weight: 12.84kg
• Tilt: 288°
• Tilt Locking System: Yoke positions included (optional Yoke)

Installation

• Mounting point on fixture top & rear side: 2x 1/4 turn Omega Bracket
• Mounting point with optional Rigging Bracket G2: 2x/4x 13mm / 1/2″ holes for Clamp fixation
• Mounting point by optional Yokes (vertial mount): 1x/3x 13mm / 1/2″ holes, 1x centric TV Spigot attachment, 1x/3x integrated Camlocks for Omega Brackets
• Orientation: Any
• Rigging possibilities: direct or due optional rigging accessories
• Safety features: 2x rear mounts for fixture & accessory safety wire
• Minimum distance from flammable materials: 0.3 meters
