Main Outputs

• Output Type: Modular
• Production Outputs: 2
• Genlock: No
• Software EDID Emulation: Yes

Control Output

• Output 1 Type: DP 1.4
• Genlock: No
• Software EDID Emulation: Yes
• Output 2 Type: HDMI 2.0
• Genlock: No
• Software EDID Emulation: Yes

Connectivity

• 1Gb Network: 2
• 10Gb Network: 2
• Above 10Gb Network: No
• Audio Out: Balanced Stereo XLR
• Audio In: Stereo 1/8″ TRS
• LTC over Audio Input: Yes
• Rear USB Ports (Type-A): 2 x USB3.2gen1
• Rear USB Ports (Type-C): 1 x USB3.2gen1
• Front USB Ports (Type-A): 2 x USB3.2
• Front USB Ports (Type-C): 1 x USB3.2gen1
• Power Input: Neutrik True1
• Power Loop: True1 - 1000W Max

Physical Specifications

• Size (Rack Units): 2
• Installed Depth: 605mm ( 645 w/ Ears)
• Installed Width: 425mm (485 w/ Ears)
• Installed Weight: 16 Kgs
• Mounting: Front Rack Rails
• Voltage: 100-250V 50/60Hz
• Power Consumption (Max): 800W
• Heat Dissipation (Max): 2500 btu/hr
• Min Operating Temp: 0C / 32F
• Max Operating Temp: 35C / 95F
• Min Storage Temp: 0C / 32F
• Max Storage Temp: 35C / 95F
• Max Humidity (Non-Condensing): 95%

Technical Specifications

• CPU Cores / Threads: 8(16)
• CPU Base Clock: 3.8GHz
• Memory: 32GB
• Memory Type: DDR5-5200
• OS Drive: 500GB SSD
• Media Drive Size: 4TB
• Media Drive Speed: 6,500 MB/s
• Concurrent 4K Layers: 18
• Layers per Mix: 16
• Mixes: 12
• Notch Marks: 31,434
