Technical Specifications

Description

SOURCE

  • Light source: 300W LED white light module
  • Color temperature: 8000K
  • Output: 5000 lm
  • Illuminance: at 10m illuminance 16700 lx/spot of 0.35m
  • LED Life expectancy: 20,000 hours

OPTICAL SYSTEM

  • Beam angle: 3° to 39°
  • Electronic Focus

DYNAMIC EFFECTS

  • Dimmer: 0-100% linear adjustment
  • Electronic Strobe
  • Color mixing: CMY
  • Color wheel: 9 colors + white
  • Static gobos: 11 gobos + open
  • Rotating gobos: 7 gobos + open
  • Rotating gobo size: OD= 23.9mm, ID=13mm
  • Prism: 5 facets prism
  • Frost
  • High precision positioning system

CONTROL & PROGRAMMING

  • Control Protocols: DMX, Auto
  • Channel mode: 16, 24 channels
  • Display: 1.7 inch screen display, can reverse 180°

MOVEMENT

  • Pan: 540°
  • Tilt: 270°
  • Resolution: 16Bit

ELECTRICAL

  • Input voltage: AC110-240V/50-60Hz
  • Power consumption: 400W

PHYSICAL

  • IP Rate: IP20
  • Product size: 325x240x570 m m
  • Weight: 13.5 kg
