The cabinet construction uses marine grade birch plywood as well as aircraft grade aluminum and steel, and is equipped with two Speakon™ NL4 connectors (IS10), or barrier strips (IS10b). A plate and screw rigging system is recessed in the interior of the rear rigging fins for easy assembly.

The IS10 is suited to a wide variety of applications. Its full range capability (60 Hz) at reasonable levels qualifies for applications where sub is not required. Increased vertical coverage (10°) enables the IS10 to cover theaters, arenas and stadiums with reasonable speaker quantity. Other target applications include dance clubs, large meeting rooms and contemporary churches.

Specifications:

• Frequency Range (+/-3 dB): 60 Hz - 18 kHz
• Nominal Directivity (-6 dB): H x V 110° x 10°
• Maximum Peak SPL**: 141.3 dB
• Components LF: 2 X ND10-LM
• Components HF: Adamson NH4TA2 4” Diaphragm / 1.5” Exit Compression Driver
• Nominal Impedance LF: 8 Ω
• Nominal Impedance HF: 8 Ω
• Power Handling (AES / Peak) LF: 700 / 2800 W
• Power Handling (AES / Peak) HF: 160 / 640 W
• Rigging : Integrated Rigging System
• Connection: 2x Speakon™ NL4 or Barrier Strips / IP67 Cable Gland with Weatherized
• Height Front (mm / in): 300 / 11.8
• Height Back (mm / in): 175 / 6.9
• Width (mm / in): 737 / 29
• Depth (mm / in): 518 / 20.4
• Weight (kg / lbs): 25 / 55.2
• Supported Processing: Lake**12 dB crest factor pink noise at 1m, free field, using specified processing and amplification
