The onboard WiFi can receive sACN and Art-Net, while the Bluetooth interface enables configuration via the CRMX Toolbox App and streaming of DMX. The 5-pin XLR can be used as input or output for DMX/RDM from any source making the Aurora act as a protocol converter.

With the intuitive color screen it’s easier than ever to configure locally, using the rotary knob to move between setting and universes. For even more control the CRMX Toolbox App is capable of configuration from any smart device.

LumenRadio continues to deliver the most reliable Wireless DMX with both CRMX and W-DMX compatibility, featuring Linking Key* along with industry standard 5 ms latency, error correction and 128 bit encryption at full refresh rate for a full universe.

Key Features:

• Single Universe CRMX Flex unit
• DMX/RDM, sACN and Art-Net 1-3
• 5 GHz WiFi and Bluetooth
• Configuration via App or Front panel
• Compatible with CRMX and W-DMX G3/G4s

Product Specifications:

• DMX / RDM
• sACN / Art-Net 1-3
• CRMX
• W-DMX G3 / G4s
• WiFi IEEE802.11b/g/n/ac
• Bluetooth 5.0

• Frequency range: 2402-2480 MHz
• Radio module: TimoTwo
• 5ms latency
• 128-bit encryption
• Forward Error Correction

• Antenna: RP-TNC
• DMX: 5-pin XLR female
• DC: 2.5mm/5.5mm Barrel connector
• AC: powerCON Tru1

• DC 10-20v
• AC 100-240 VAC

• IP20 Aluminium enclosure
• Front panel color screen and rotary knob
• M10 and ⅜” Threads
• Rack and wall mount accessories
• V-Lock battery mount accessory
• 14 x 20 x 4.4 cm
