TECHNICAL SPECIFICATIONS

Optics

• 2-elements 10:1 zoom high-resolution optic system
• Beam aperture: 3° to 30°
• Fast motorised linear zoom
• 100 mm front lens

Light source

• 5,000 lm RGB-L LED source
• Total luminaire output: up to 3,000 lm
• Illuminance at 5m: 16,000 lux
• CRI: up to 86
• Rated life (L70): up to 40,000 hours
• Flicker free sources management, suitable for TV applications and all video recorded events

Movement

• Extremely accurate positioning
• Moving-head operated via either 8- or 16-bit resolution
• High-resolution stepper motors operated via microprocessors to ensure extreme accuracy and smooth movement
• Pan and tilt automatic repositioning
• Moving-head range: infinite pan and tilt rotation

Colours

• Sophisticated 4 colours RGB-L mixed, reaching high Colour Rendering Index
• Uniform light beam with no colour shadows, and rich saturated and pastel colour-hues
• 4.29 billion colours (8-bit resolution)
• Virtual CTC channel, from 2500 to 8000K
• Virtual Tint channel

Effects

• Liquid Effect with 60 individual pixels
• Built-in pattern effects with speed and fade control

Dimmer / Strobe

• Electronic dimmer from 0 to 100%
• Strobe effect: 1 to 25 flashes per second

Hardware features

• Graphic LCD display with flip function
• 4 menu buttons to set functions
• Integrated wireless CRMX TiMo RDM receiver from LumenRadio
• IP65 XLR 5 pin male and female connectors for DMX connection
• IP65 RJ45 IN / OUT connectors for ArtNet connection
• IP65 PowerCON TRUE1 TOP male and female connectors for power connection

Control

• DMX 512 protocol, through IP65 DMX cable or wireless system
• DMX-RDM compatible
• Stand-alone mode and Main/Follow modes
• ArtNet & sACN protocol through IP65 Ethernet cable
• Local control panel, with IP65 LCD display
• Footprint of 35 DMX channel

Power supply

• Electronic supply with active PFC
• 100 to 240 Volts – 50/60Hz
• Power: 160 W maximum

Cooling system

• Advanced liquid cooling system
• IP68 Self-adjusting variable speed fans
• Selectable ventilation user modes
• Safety protection against excess temperature

Housing

• Moving-head skeleton made in die-cast aluminium
• Base in die-cast aluminium
• Heatsinks in aluminium and copper
• Moulded covers ABS PC (V0 class)
• Two handles for transportation
• Four heavy-duty feet
• IP65 protection rating
• Exterior finish: black (Carbon)

Installation

• Fastening bracket system: two Omega ¼ turn brackets designed for use with standard clamps
• Mounting points: two ¼ turn locking fittings allowing installation of Omega brackets on luminaire
• Safety cable attachment point

Operating parameters

• Operating positions: all (device on floor or fixed to a support)
• Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
• Minimum permitted ambient temperature (Ta min): -20 °C (-4 °F)
• Minimum usage distance: 0.5 m (1.64 ft.)

EU (EMC & LVD):

• EMC Directive 2014/30/EU
• LVD Directive 2014/35/EU

US (Safety & EMC)

• UL 1573
• FCC Part 15, Subpart B:2018

Size

• Product: 197 x 353 x 197 mm (l x h x d)
• Flight-case foam (dual): 500 x 310 x 250 mm (l x h x d)

Weight

• Product: 6.6 kg
