Photometrics

• LED expected lifetime: 50,000 hours
• Lightsource: 24x 40W RGBL
• Type of optical system: Lightrod & PC Zoom lens
• LED PWM Frequency: Selectable 800Hz, 1.300Hz, 2.000Hz, 3.600Hz, 12kHz, 25kHz
• Total Zoom Beam / Field angle: 4.5° - 70° (50% beam) / 6,9° - 142° (10% fi eld)
• Optical (Motor) Zoom Beam / Field angle: 4.5° - 30° (50%) / 6,9° - 40° (10% fi eld)
• Color temperature range: 2000-10.000K
• CRI/Ra @ 5600K: 76 @ Normal CRI / 85 @ High CRI
• TLCI @ 5600K: 63 @ Normal CRI / 75 @ High CRI
• TLCI mixed @ 11.000K: 85
• Luminous flux @ 5600K (wide zoom / normal CRI): 12.300lm
• Illuminance Lux @ 5m / 16,4ft (@ Full / RAW) @narrow zoom: 59.820lx
• Illuminance Lux @ 5m / 16,4ft (@ 5600K Normal CRI) @ narrow zoom: 56.790lx
• illuminance Lux @ 5m / 16,4ft (@ 5600K High CRI) @ narrow zoom: 34.780lx
• Efficancy @ Full 230V (max): 12.30 lm/W

Dimensions & Weight

• IP class: IP65
• IK class: IK08
• Body material: Magnesium, Aluminum, Nylon
• Lens material: Tempered glass front
• Net dimensions (w x h x d) - head straight up: 521 x 347 x 245
• Net dimensions inches - head straight up: 20.52 x 13.66 x 9.65
• Net weight: 24.15 kg / + Filter 24.8 kg
• Tilt: 188°
• Tilt Locking System: Mechanical locking system

Thermal Characteristics

• Cooling: Active, Forced Air, Temperature-regulated
• Humidity (max.): 95%
• Temperature range, Operating -40°C to 45°C
• Temperature range, Start-Up -20° to 45°C
• Temperature range, Storage: -40°C to 80°C
• Thermal Protection: Automatic overtemperature protection

Electrical Data

• AC Power, max: 90 – 285V 50/60Hz
• AC Power, nominal: 100 – 240V 50/60Hz
• Electrical protection: Overload protection with automatic recover
• power consumption (Boost Mode): 1234W @ 230V / 1310W @ 100V
• Constant power consumption (Illumination Mode): 1000W @ 230V / 1055W @ 100V
• Power Max. Out @ Max. Power Consumption (Boost Mode): 5.55A @ 230V (1234W) / 13.44A @ 100V (1310W)

Electrical Data

• Power Max. Out @ Constant Power Consumption (Illumination Mode): 4.44A @ 230V (1000W) / 10.6A @ 100V (1055W)
• Power Linking @ Max. Power Consumption (Boost Mode): 2 units @ 230V / 1 units @ 100V
• Power Linking @ Constant Power Consumption (Illumination Mode): 2 units @ 230V / 1 units @ 100V
• Power Factor @ Max. Power Consumption (Boost Mode): 0.993PF @ 100V / 0.976PF @ 230V
• Power Factor @ Constant Power Consumption (Illumination Mode): 0.994PF @ 100V / 0.976PF @ 230V
• Standby Power: 40W
• Power Supply Unit: Inbuilt auto-ranging electronic switch-mode

Operator & Controller

• DMX Channels: 15CH RGB, 19CH RGB, 26CH RGB, 30CH RGB, 28CH DIRECT, 33CH DIRECT, 81CH
• PURE, 154CH PURE, 9CH Dual mode, 10CH Dual mode, 95CH FULL ACCESS, 168CH FULL ACCESS
• DMX Modes: 12
• Protocol: USITT DMX512A RDM ANSI E1.20 Art-Net sACN CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S Bluetooth (Low Energy)
• Setting and addressing: 2.0" TFTdisplay / 10 controls: RDM ANSI E1.20 Near Field Control (NFC)
• Standalone mode: Auto Program, Color Macro, Quick Color, Tunable White, User Color
• Wireless DMX: Lumen Radio transmit & receive function (CRMX)
• Indicator: 2.0" TFT display
• Controls: 10 backlighted controls
• Strobe LED: 0-30Hz
• Strobe Smart Glass: 0-5Hz
• DMX I/O: IP65 XLR 5-pin male/female
• Ethernet I/O: IP65 RJ45 Ethernet male/female
• Power In: TRUE1 compatible input & link-thru sockets
• USB Firmware: Update IP65 USB socket

Included / Optional

• Included items: 2m Power Cable
• Optional Accessories: Smart-Glass Filter (electronic frost), magnetic filter (elliptical-horizontal), Grid, Omega Bracket ST

Installation

• Mounting point on fixture bottom side 3x 1/4 turn Omega Bracket
• Mounting point on fixture Yoke side 1x 1/4 turn Omega Bracket
• Orientation: Any
• Rigging possibilities: Hanging direct
• Safety features: 1x bottom mount for fixtures safety wire / 2x head-mount (handle) for accessory safety wires
• Minimum distance from flammable materials 0.3 meters
