The Matrix also provides advanced features including independent DolbyAudio & DTS Audio down mixing on HDMI and audio outputs allowing amixture of different audio output formats for use with different audiocapable displays and AV amplifiers.The PLA88CS also includes independent audio routing, Audio ReturnChannel (ARC), audio delay for lip sync correction, bi-directional IR andRS-232 pass-through, and web-GUI for control and configuration.

Key Features:

• Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
• 4x Simultaneous HDBaseT™ and HDMI outputs to allow connection to dual displays per zone
• Extends HDMI up to distance of 150m at 1080p, and 4K UHD video up to 100m (up to 4K 60Hz 4:4:4) using LRM (Long Range Mode)
• Features 8x HDMI inputs which can be independently routed to 4x HDBaseT™, and 4xHDBaseT™ / HDMI outputs
• 2x HDBaseT™ CSC inputs for connectivity to remote video sources not located locally to the Matrix
• Independent video scaling on allHDBaseT™ outputs
• Independent Dolby Audio & DTS Audio down mixing on HDMI and audio outputs
• Up to 24x16 Audio Matrix independently controllable from video:-
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Bi-directional IR & RS-232 from all input and output locations (with compatible Transmitters & Receivers)
• Integrated Ethernet (100Mbps) switch (LAN Serving) when used with Blustream RX150CS Receivers
• Web interface module for control and configuration of the Matrix
• Control of Matrix via front panel , IR, RS-232, and TCP/IP
• Supports 24V PoC (Power over Cable) to power compatible RX150CS or RX70CS Receivers
• 3rd party drivers available for major control brands
• HDCP 2.2 compliant with advanced EDID management
• 2U Design for 19” rack mount integration - mounting kit included
• Recommended receiver: RX150CS (where 18Gbps CSC, Long Range Mode, LAN, Audio Return, and 24V PoC support is required)
• Optional receiver: RX70CS (where 18Gbps CSC, Audio Return, and 24V PoC support only is required) - max distance 70m at 1080p, 40m at 4K 60Hz 4:4:4

• 2x analogue L/R and 2x Optical (S/PDIF) audio inputs which can be routed to audio outputs, or embedded onto HDBaseT™/ HDMI outputs
• HDMI audio breakout to Optical (S/PDIF) digital, or analogue L/R audio outputs with variable pre-amp line level control
• Supports ARC (Audio Return Channel) via HDMI or Optical (S/PDIF) digital inputs from compatible RX150CS Receivers
• Supports full Dolby Audio and DTS Audio down mixing from HDMI inputs to 2ch audio

Specifications:

• Video Input Connectors: 8 x HDMI Type A, 19-pin, female, 2 x HDBaseT™ RJ45 connectors
• Video Output Connectors: 4 x HDMI Type A, 19-pin, female, 8 x HDBaseT™ RJ45 connectors
• Audio Input Connectors: 2 x Analogue audio L/R (3.5mm stereo Jack), 2 x Optical (S/PDIF)
• Audio Output Connectors: 8 x Analogue audio L/R (3.5mm stereo Jack), 8 x Optical (S/PDIF)
• RS-232 Serial Port: 9 x 3-pin Phoenix connector
• TCP/IP Control: 1 x RJ45, female
• Ethernet/Network: 1 x RJ45, female
• IR Input Ports: 10 x 3.5mm stereo jack
• IR Output Ports: 9 x 3.5mm mono jack
• Rack Mountable: 2U rack height, rack ears included
• Casing Dimensions (W x H x D): 440mm x 87mm x 361mm (without feet)
• Shipping Weight: 8.8kg
• Operating Temperature: 32°F to 104°F (0°C to +40°C)
• Storage Temperature: -4°F to 140°F (-20°C to +60°C)
• Power Supply: Internal 100-240V AC

Box Contents:

• 1 x PLA88CS
• 1 x Rack Mounting Kit
• 1 x Remote Control
• 9 x IR Emitters
• 9 x IR Receivers
• 9 x IR Control Cable - 3.5mm to 3.5mm
• 2 x Serial Cable - DB9 to 3-pin Phoenix Connector
• 9 x 3-Pin Phoenix Connector
• 1 x Quick Reference Guide
• IEC Power Cable(s)
