Key Features:

• Highly reliable NEUTRIK® powerCON® TRUE1® TOP recepticals for In and daisy chaining, Mains receptacles Schuko Type E/F
• Flame retardant (UL94-V2) and non-conductive housing material
• High outdoor protection (IP54, IK, ..)
• Light weight, compact and stackable housing design
• Versatile mounting options

Applications:

• Markets:Professional video wall / lighting / audio
• Mobile application:Festivals, live events
• Semi-permanent applications:Theaters, studios

Technical Specifications:

Product

• Input device: 1x powerCON® TRUE1® TOP
• Output device: CPPSE6RD-TT: 6x Schuko Type E with self-closing caps |
• CPPSF6RD-TT: 6x Schuko Type F with self-closing caps
• Daisy chaining: 1x powerCON® TRUE1® TOP with self-closing caps

Electrical

• Contact resistance / protection class: Protection class II
• Dielectric strength: 0,5 kV / mm
• Rated voltage: 250V AC
• Rated Current: 16 A
• Number of electrical contacts: 2 + PE
• Phases: single-phase

Mechanical

• Dimensions: 384.7 x 77 x 100.6mm
• Conductor cross section: 2,5mm²
• Weight: 1.25 kg
• Mounting options: Truss clip, mounting wholes for pegging or suspension

Material

• Housing: Easylen
• Color: black

Environmental

• Standards compatibility: UL94-V2
• Protection class: IP54
• Temperature range: -25 °C bis +70°C
