Technical Specifications

Description

Key Features:

  • High power capacitythanks to the CEE32A connector
  • Circuit protectionagainst overload for each of 6x Outs with separate MCB
  • High durability & protection: rugged Easylen® housing with high IK, high IP with CEE connector in mated condition, self-closing caps, flame retardant & non-conductive housing material
  • Easy transport & handling: stackable with other Power Turtles, lightweight, fully lockable
  • Versatile mounting options: pegs, suspension, truss clamp

Applications:

  • Markets: Professional video wall / lighting / audio
  • Mobile application: Festivals, live events
  • Semi-permanent applications: Theaters, studios

Technical Specifications:

Electrical

  • Circuit protection: 6x MCB (1-pole)
  • Phase control indicator: L1, L2, L3, green
  • Contact resistance / protection class: Protection class II
  • Dielectric strength: 0,5 kV / mm
  • Rated voltage: 415V AC
  • Rated Current: 16A
  • Number of electrical contacts: 4 + PE
  • Phases: three-phase

Mechanical

  • Dimensions: 225 x 155 x 188 mm
  • Weight: 3,3 kg
  • Conductor cross section: OUT: 2,08 mm²
  • Daisy chaining: 6 mm²
  • Mounting options: Truss clamp (M10), mounting wholes for pegging or suspension
  • Type of construction: Stackable

Material

  • Housing: Easylen
  • Color: black

Environmental

  • Flammability acc. to UL 94: V-2
  • Temperature range: -25 °C bis +40°C
