The cabinet construction uses marine grade birch plywood as well as aircraft grade steel and aluminum, and is equipped with two Speakon™ NL8 connectors. The rigging system incorporates the best aspects of previous advancements in our new SlideLock rigging technology.

The S10 is suited to a wide variety of applications. Its full range capability (60 Hz) at reasonable levels qualifies for applications where sub is not required. Increased vertical coverage (10°) enables the S10 to cover theaters, arenas and stadiums with reasonable speaker quantity. Other target applications include dance clubs, medium size festivals, corporate events and contemporary churches.

Specifications:

• Frequency Range (+/-3 dB): 60 Hz - 18 kHz
• Nominal Directivity (-6 dB): H x V 110° x 10°
• Maximum Peak SPL**: 141.3 dB
• Components LF: 2x ND10-LM 10" Kevlar® Neodymium Driver
• Components HF: 1x NH4TA2 4" Diaphragm / 1.5" Exit Compression Driver
• Nominal Impedance LF: 2x 16Ω(8Ω)
• Nominal Impedance HF: 8Ω
• Power Handling (AES / Peak) LF: 2x 350 / 2x 1400 W
• Power Handling (AES / Peak) HF: 160 / 640 W
• Rigging: Slidelock Rigging System
• Connection: 2x Speakon™ NL8
• Height Front (mm / in): 265 / 10.4
• Height Back (mm / in): 178 / 7
• Width (mm / in): 737 / 29
• Depth (mm / in): 526 / 20.7
• Weight (kg / lbs): 27 / 59.6
• Supported Processing: Lake**12 dB crest factor pink noise at 1m, free field, using specified processing and amplification
