Technical Specifications

Optics

• 13-element 13:1 zoom
• Beam aperture: 4 ° to 52 °
• 140 mm front lens

Light Source

• 25,000 lm white light engine
• Luminaire output: up to 20,000 lm
• Colour temperature output: 6500 K
• Variable CRI: 70 to 86
• Rated life (L70): up to 40,000 hours
• Flicker-free source

Movement

• Highly accurate positioning
• Resolution: 8- or 16-bit
• Smooth movement
• Pan and tilt automatic repositioning
• Range: infinite pan and tilt rotation

Colours

• Sophisticated CMY colour mixing
• Variable CTO
• Variable CRI channel up to 86
• 7 complementary colours
• Multicoloured section

Gobos

• 9 indexable rotating glass gobos
• Adjustable-speed rotating gobo
• 10 fixed glass gobos
• Image diameter: 13 mm

Framing System

• 4 individually shutter blades
• Positionable on 100% surface area
• Rotation of the module: +/- 90 °

Iris Diaphragm

• 15-blade iris diaphragm
• Range: 15% to 100% open

Frost

• 2 frost filters: one light, one heavy

Prisms

• 2 combinable rotating and indexable prisms
• One 5-facet circular, one 4-facet linear

Effects

• Focusable graphic animation effect-wheel
• Continuous rotation in both directions

Dimmer /Strobe

• Electronic dimmer from 0 to 100%
• Strobe effect: 1 to 25 flashes per second

Hardware Features

• Graphic LCD display with flip function
• 5 menu buttons to set functions
• Integrated LumenRadio™ receiver
• IP65 XLR 5 pin connectors
• IP65 RJ45 connectors
• IP65 powerCON TRUE1 TOP connectors

Control

• DMX 512 protocol
• DMX-RDM compatible
• Stand-alone mode, Local control panel, with IP65 LCD display
• ArtNet & sACN protocol
• 2 DMX modes (42 to 65 DMX channels)

Power Supply

• 100 to 240 Volts – 50/60Hz
• Power: 580 W maximum

Cooling System

• Advanced liquid cooling system
• IP68 Self-adjusting variable speed fans
• Selectable ventilation user modes
• Excess-temperature protection

Housing

• Skeleton made of aluminium
• Base in die-cast aluminium
• Heatsinks in aluminium and copper
• Moulded covers ABS PC (V0 class)
• Four handles on the yoke
• Four heavy-duty feet
• IP65 protection rating
• Exterior finish: black (Carbon)

Installation

• Two Omega ¼ turn brackets
• Four ¼ turn mounting points
• Safety cable attachment point

Operating Parameters

• Maximum temperature: 45 °C (113 °F)
• Minimum temperature: -20 °C (-4 °F)
• Minimum usage distance: 2 m (6.56 ft)

Compliance

• EMC Directive 2014/30/EU
• LVD Directive 2014/35/EU
• US Safety: UL 1573 & FCC Part 15, Subpart B: 2018

Size

• Product: 338 x 592 x 297 mm (l x h x d)
• Foam: 390 x 500 x 510 mm (l x h x d)

Weight

• Product: 23.5 kg
