Technical Specifications

Description

Key Features
β€’ Features 4 x HDMI inputs which can be switched to single HDMI output
β€’ Supports full HDMI 2.0 specification 4K UHD video (4K 60Hz 4:4:4) with HDR
β€’ HDCP 2.2 compliant
β€’ Supports 3D signal display
β€’ Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
β€’ Auto, manual or priority switching capabilities. Auto switching from TMDS or 5V HPD
β€’ Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
β€’ HDMI audio breakout to phoenix balanced / unbalanced analogue audio and optical (S/PDIF) digital outputs concurrently
β€’ Control via IP, RS-232, web GUI, front panel, and IR
β€’ Advanced EDID management
β€’ Auto-standby mode

Product Specifications
β€’ Video Input Connectors: 4 x HDMI Type A, female
β€’ Video Output Connectors: 1 x HDMI Type A, female
β€’ Audio Output Connectors: 1 x Optical (S/PDIF) & 1x 5-pin Phoenix analogue audio
β€’ TCP/IP Input Ports: 1 x RJ45 (female)
β€’ IR Input Ports: 1 x 3.5mm stereo jack (5V)
β€’ Casing dimensions (W x H x D): 234mm x 23mm x 94mm
β€’ Dimensions including connections (W x H x D): 196mm x 32mm x 99mm
β€’ Shipping weight: 0.9kg
β€’ Operating temperature: 32Β°F to 104Β°F (0Β°C to 40Β°C)
β€’ Storage Temperature : -4Β°F to 140Β°F (-20Β°C to 60Β°C)
β€’ Power Supply: 5V/1A DC, screw barrel

Box Contents
β€’ 1 x SW41AB-V3
β€’ 1 x REMSW41V3 (no battery)
β€’ 1 x 5V/1A DC power supply
β€’ 1 x IRR - IR receiver (5V)
β€’ 1 x Quick Reference Card
