Key Features

• Supports HDMI 2.0b 18Gbps specification, including 4K 60Hz 4:4:4 UHD video
• Supports distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision
• HDMI output 1 replicates the HDMI input signal - up to 4K 60Hz 4:4:4 and 5.1.4ch / 7.1.2ch Dolby Atmos and DTS-HD multi-channel audio
• HDMI output 2 features an optional 4K video down-scaler, and 5.1.4ch / 7.1.2ch to 2ch Dolby Atmos and DTS-HD audio downmixing
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• HDMI audio breakout of Dolby Atmos and DTS-HD to up to 8 channels of Dante audio (7.1ch), with an independent 2 down-mixed channels of Dante audio
• HDMI audio breakout of Dolby Atmos and DTS-HD to up to 10 channels of Dante audio (7.1.2ch / 5.1.4ch)*
• HDMI audio breakout to 7.1ch balanced / unbalanced analogue audio outputs
• HDMI Dolby Atmos and DTS-HD 7.1 down-mixing to 2ch balanced and unbalanced audio ouputs
• Supports ARC/eARC including breakout to 7.1ch and 2ch downmixed analogue, and Dante audio
• Supports: 44.1, 48, 88.2 & 96kHz Dante® sample rates @ 24-bit
• Configurable Dante® device latency using Dante® Controller
• Supports AES67 RTP audio transport
• Control via TCP/IP, web-GUI, RS-232, front panel buttons, and infrared
• HDCP 2.3 compliant with advanced EDID management

Specifications

• Audio Input Connectors: 4 x Optical (SPDIF)
• Output Connectors: 1 x Optical (SPDIF), 1 x RCA (SPDIF) & 1 x Analogue audio L/R (3.5mm stereo jack)
• IR Input Ports: 1 x 3.5mm stereo jack
• Product Dimensions (W x D x H): 140 x 80 x 25mm (with connections)
• Product Dimensions (W x D x H): 140 x 70 x 25mm (without connections)
• Product Weight: 0.25kg (excluding accessories)
• Carton / Box Dimensions (W x D x H): 210 x 125 x 90mm
• Shipping Weight: 0.5kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Power Supply: 5V/1A DC, screw type connector
• Mounting Kit Included
