The four closely-spaced cone drivers provide true line array characteristics:phase coherence,low distortionandfocused listeningin both the near field and at a distance from the speaker.

Two different values ofimpedance(8Ω – 32Ω) allow to connect up to8xVyper-KV25 II loudspeakers at 32Ω impedance to the same 4Ω amplifier output channel, which eliminates the need for 70V lines for wide distributed installed systems where pristine sound, intelligibility and elegance are mandatory.

Key Features:

Technical Specifications:

GENERAL

Type: Line array

Transducers: 4 x 1" neodymium magnet woofers

Frequency Response: 150 Hz – 18 kHz (-6 dB)(1)

Max SPL: 108 dB (peak)(2)

Rated Power: 75 W

Coverage: V. 25° | H. 140°

Connectors: 2PIN euroblock connector (included)

Nominal Impedance: 8 Ω / 32 Ω selectable

HANDLING AND FINISHES

Dimensions (W x H x D): 40 x 260 x 22 mm (1.56 x 10.24 x 0.85 in)

Weight: 0.4 kg (0.88 lb)

Material: Aluminum

Colors: Black, White, Custom Ral

Finishes: 24K Gold, Polished

REGULATIONS

IP Rating: IP65

With dedicated presetMaximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 8 m then scaled at 1 m
